Y-IS OSM Test Socket - Single Size

Features

  • One socket size for module sizes 0, S, M, L
  • Available PCB can be re-used
  • Mid volume test socket
  • Usable for Pad, Bumb and Ball style modules
  • Exchangeable pusher
  • Easy module handling and socket closing
Request Product

Advantages

  • Single socket size for individual module types
  • Robust design
  • Compression Mount Technology for quick installation and maintenance

Specifications

General Specification
  • Mating Cycles
    50,000
  • Operating Temperature Range
    -55 °C – 150 °C
  • Socket Type
    Clamshell
Electrical Specification
  • (Initial) Contact Resistance
    50 Milliohm
  • Current Rating
    1.2 A
Interface Specification
  • Pitch
    1.25
